Hidance 12 in 1 usb energy meter tester with bluetooth app
€ 43,75
Hidance 12 in 1 usb energy meter tester with bluetooth app
The Hidance J7-c is a 12-in-1 multifunctional USB energy meter with an accompanying Bluetooth app for in-depth power analysis for electrical DIY enthusiasts. It delivers an accuracy class of 1%, utilizing a software calibration technique and <2mR alloy sampling.
The durable device is made from hard PC with a pure copper USB pin and a 5C transparent protective film, ensuring longevity and reliability in a compact size of 60*60*11 mm.
This energy meter supports a wide operating temperature range of -10+60°C and can measure various parameters with a high resolution: voltage (3.60-30.0 V), current (0.00-5.10 A), capacity (0–99999 mAh), and power (0–999999 mWh), among others.
Its data storage uses EEPROM capable of 3500000 autotype, and it features customizable button operations for ease of use.
For convenience, HIDANCE provides downloadable apps for both iOS and Android, enabling users to monitor and store measurements from anywhere. The unit also includes a multi-functional button allowing for screen rotation, data reset, and changes in data storage groups.
With CE certification and origin from Mainland China, the HIDANCE tester is a reliable tool for precise electrical measurements.
29 in stock
15 reviews for Hidance 12 in 1 usb energy meter tester with bluetooth app
Only logged in customers who have purchased this product may leave a review.
Hidance 12 in 1 usb energy meter tester with bluetooth app
- Power Supply: DC
- Model Number: J7-c
- Dimensions: 60*60*11mm
- Operating Temperature: -10-60C
- Accuracy Class: 1% (Software calibration technique)
- Display Type: Analog and Digital
- DIY Supplies: ELECTRICAL
- Brand Name: HIDANCE
- Origin: Mainland China
- Certification: CE
- Alloy sampling technique: <2mR (Metal Manganin resistor Sampling technique)
- Boot screen: Display: Welcome!
- Data storage type: EEPROM (3500000 autotype)
- USB pin material: Pure copper metal
- Display panel type: Dot matrix LCD module display
- MCU chip storage: Flash memory
- Shell material: Add hard PC highlights material
- Protective film: 5C high transparent protective film
APP Download address
1.http://www.mediafire.com/folder/31bc15uhq8odb/E-meter
2, IOS APP: search E_test on iphone APP store to download
3. Android APP: https://www.mediafire.com/file/0jiio43c0vuu1wx/U_Meter-Phone_mobile.apk/file
Key button operation instructions
1. Short press the button to switch the screen,
2. Quickly double-click the capacity(mAH) to clear zero ,
3. Quickly three-click the power( WH) to clear zero,
4. Fast four-click time to clear zero,
5. The quick five-click is to change the cumulative data storage group number (NO.X, 10 groups of data),
6. Long press button the capacity and power time to clear all at once,
7. In the (Screen rotation) interface, long press the button to rotate the screen;
8. When the short key is pressed to the overvoltage, low pressure and overcurrent setting interface, the value can be adjusted by quickly double-clicking or quickly three-clicking.
Production Description
Measurement Ranges (and resolution accuracy):
- Voltage: 3.60 – 30.0 V (0.01 V)
- Current: 0.00 – 5.10 A (0.01 A)
- Capacity accumulation: 0 – 99999 mAh (0.001 Ah)
- Power accumulation: 0 – 999999 mWh (0.01 Wh)
- Power calculation: 000.000 – 150.0 W (0.01 W)
- Impedance: 1 – 999.9 Whr (0.1 Ω)
- Temperature: 0 – 80 °C (1 °C)
- Timing time: 999H59M59 S (1 S)
- USB D+ voltage: 0 – 2.99 V (0.001 V)
- USB D- voltage: 0 – 2.99 V (0.001 V)
Product Details:
Input Interface: Type-C / Micro USB / USB
Output interface: Type-C / USB
Timed charge reminder settings: 24-hour countdown
Full charge threshold parameters: < 2 W / 0.5 hours
Refresh time: > 500mS / time
Measurement rate: about 0.5 time / S
Alarm mode: siren sound and display prompt (double warning)
Display type: micro-power LCD module LCM white font in English display
Product dimensions: 60 x 60 x 11 mm
Current consumption: < 0.02 A
Operating temperature: -10 to +60 °C
Working humidity: 10 to 80 (no doubt)
Work oppression: 80 – 106 Kpa
| ships to: |
|---|
EN
Although it is cheap and functions, there is also a calibration function, professional use is also possible.
It is a good choice with a USB tester.
It is convenient to have a U-shaped or L-shaped connector because the dongle cannot be attached directly to the smartphone.
