USB UPS 18650 battery charger module 5V 9V 12V 15W boost converter
€ 7,45 – € 7,96
►This smart 18650 lithium battery charger module features Type-C input with DC-DC step-up boost converter technology. The boost circuit delivers peak power up to 20W with rated power of 15W, achieving 96% efficiency through built-in 12A high current MOS design.
►Perfect for DIY electronics projects requiring UPS (Uninterruptible Power Supply) functionality. Output options include 5V at 3A, 9V at 1.6A, and 12V at 1.2A current ratings. The module automatically switches between external power and battery backup.
►Compact SMD design with dual protection functions ensures safe charging and discharging. Dimensions: 25 x 19 x 10mm with 1A adjustable charging current. Ideal for portable devices, emergency power backup, and electronic prototyping.
►Simply connect your 18650 batteries and USB Type-C power source – no additional components needed.
High Concerned Chemical: None
Model Number: Type-C 15W 3A 18650 Lithium Battery Charger Module
Origin: Mainland China
Package: SMD
Dissipation Power: 15W (Peak 20W)
Supply Voltage: 5V 9V 12V
Application: Computer, Electronics, UPS Systems
Type: DC-DC Step Up Boost Converter Module
Brand Name: baishundianzi
Condition: New
Dimension: 25 x 19 x 10mm (L×W×H)
Input Interface: Type-C USB
Charging Current: 1A (Adjustable)
Output Current: 5V/3A, 9V/1.6A, 12V/1.2A
Efficiency: Up to 96%
Static Power Consumption: 25mA
Product Description
This intelligent 18650 lithium battery charger module combines advanced DC-DC step-up boost converter technology with UPS functionality in a compact SMD design. The module features Type-C input connectivity and delivers exceptional power conversion efficiency up to 96% through its built-in 12A high-current MOS design.
The boost circuit provides peak power up to 20W with a rated continuous power of 15W, making it perfect for demanding electronic applications. Multiple output voltage options (5V/9V/12V) ensure compatibility with various devices and projects.
Key Features & Applications
Dual Functionality: Functions as both a battery charger and UPS power supply, automatically switching between external power and battery backup without interruption.
High Efficiency Design: Advanced boost converter technology minimizes power loss and heat generation, ensuring reliable operation in compact spaces.
Safety Protection: Integrated dual protection functions prevent overcharging, over-discharging, and short circuits, extending battery life and ensuring safe operation.
Versatile Output Options: Selectable output voltages accommodate different device requirements – 5V at 3A for USB devices, 9V at 1.6A for intermediate power needs, and 12V at 1.2A for higher voltage applications.
Technical Specifications
- Input: Type-C USB connector
- Battery Compatibility: 18650 lithium-ion batteries
- Charging Mode: Linear charging with 1A adjustable current
- Boost Circuit: Built-in 12A high-current MOS
- Module Size: Ultra-compact 25×19×10mm footprint
- Power Efficiency: Up to 96% conversion efficiency
- Static Consumption: Low 25mA standby current
Perfect for DIY electronics projects, portable power banks, emergency backup systems, and electronic prototyping where reliable power conversion and battery management are essential.
USB UPS 18650 battery charger moduleUSB UPS 18650 battery charger moduleUSB UPS 18650 battery charger moduleUSB UPS 18650 battery charger module
| Voltage | |
|---|---|
| Hign-concerned Chemical | None |
| Package | SMD |
| is_customized | Yes |
| Dissipation Power | 15W |
| Supply Voltage | 5V 9V 12V |
| Application | Computer |
| Type | Module |
| Brand Name | baishundianzi |
| Origin | Mainland China |
| Condition | New |
| Operating Temperature | ℃ |
