Smart door lock fingerprint TTLock app keyless WiFi NFC IP67 B05
€ 84,49 – € 91,01
► 5-in-1 Access Methods: Fingerprint recognition, touchscreen passcode, NFC cards, TTLock app, and physical key backup
► TTLock App Control: Remote locking, unlocking, access monitoring, and visitor code generation through smartphone app
► IP67 Waterproof Rating: Aluminum alloy construction with powder coated finish for outdoor installation protection
► NFC Card Technology: Includes 2 IC cards for contactless access and phone NFC function support
► Advanced Fingerprint System: Stores up to 200 fingerprints with 99.99% recognition accuracy and 0.1 second response
► Built-in Gateway Support: WiFi connectivity with integrated gateway eliminates need for additional hardware
► Emergency Backup: USB charging port and physical key override for battery depletion situations
► Reversible Installation: Handle direction reversible for left and right-handed doors, fits 35-55mm thickness
The smart door lock model B05 features fingerprint recognition technology, TTLock app remote control capabilities, and keyless entry system with WiFi connectivity. This digital security device incorporates multiple access methods including fingerprint scanning, NFC card reading, and smartphone application control.
Access Control Methods The fingerprint door lock operates with five access methods: fingerprint recognition, numeric touchscreen passcode, NFC card readers, TTLock app control, and traditional key backup. The fingerprint sensor stores up to 200 individual fingerprints with 99.99% recognition accuracy and 0.1 second response time. The touchscreen keypad accepts 150+ passcodes for numeric entry access.
Connectivity and Remote Functions WiFi connectivity enables remote control through TTLock application on iOS and Android platforms. The app remote control system allows users to lock and unlock doors from distant locations, monitor access logs, and receive real-time notifications. NFC technology supports contactless card access using the included 2 IC cards. Built-in gateway support provides direct connectivity without additional hardware.
Construction and Weather Resistance The lock housing features aluminum alloy construction with powder coated finish and IP67 waterproof rating for outdoor installation capability. The IP67 certification indicates protection against dust ingress and water immersion. Door thickness compatibility ranges from 35-55mm for steel doors, wooden doors, brass doors, and stainless steel doors.
Technical Specifications
- Power supply: 4 AA batteries (1.5V each, not included)
- Battery backup: USB emergency charging port for external power supply
- Installation: Door thickness 35-55mm, 54mm bore hole diameter
- Wireless protocols: WiFi connectivity with built-in gateway support
- Handle direction: Reversible for left and right-handed doors
Security Features The smart door lock includes auto-locking function, wrong password lockout protection, and bank-level security with white-box cryptography. The device generates codes for visitors and guests remotely through the TTLock app. Emergency unlock capability operates through physical key override or USB power connection during battery depletion.
Installation Components The package contains face plate and back plate assemblies with rubber gasket, door handles, installation hardware, user manual in multiple languages, hole opening template, 2 IC cards, 2 keys, and slide bolt with screws. The lock system accommodates standard residential door installations with reversible handle mechanisms.
Operational Status LED indicators display battery status, lock position, and connectivity status. The touchscreen interface provides backlit operation for nighttime visibility and weather-resistant operation in outdoor environments.
Below is a video to show you how to Install the lock
Easy Installation, Easy to install in minutes with just a Phillips screwdriver.
Before installing you need to prepare 1x Phillips head screwdriver and 2pcs x AA Batteries by yourself
Widely Application
Our smart fingerprint door lock is suitable for entry doors, bedroom doors, office doors, wooden doors and so on. Easily use the smart app to generate or remove codes remotely for visitors or guests,a great solution for homeowners, short-term rental hosts and property managers.
Remote Control /WiFi Access
–White-Box Cryptography (WBC) Powered Door Codes
–Bank-Level Security
–Send one-time-use codes or long-tern codes to visitors and guest remotely
—If paired with WiFi Gateway (Optional Add-on, need to buy Separately), you can lock/unlock your smart door lock anywhere anytime, check real-time access records.
Advanced Patented Fingerprint Technology
Unlock the door in less than 0.1 second with our Advanced Patented Fingerprint Access Technology.360° recognition, more stable, 99.99% recoginition rate, High sensitivity.
5-in-1 Keyless Entry
The most secured 5-in-1 Keyless Entry Smart Door Lock: Fingerprint + Passcode + Card + App + Key.
AUTO LockingThe lock can store 150+ codes and 200+ fingerprints. Between Permanent, Timed, Custom codes, you can generate the code by your choice!Aluminum Alloy External power supply in emergency
To solve low battery situations, you can connect a power bank for power supply.
Reversible Handle
Door handle is reversible for both left and right handed doors.
Our lock works with doors with these specifcations:
Door Thickness: 33mm-50mm
Bore Hole Diameter: 54mm
Bore Hole Backset: 60mm or 70mmProduct SizeReplace knob lock without any damage on door
Different Colors Selection
Our door lock have 3 colors for your choice: silvery, black and gold.
Smart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLockSmart door lock fingerprint TTLock
| Color | |
|---|---|
| Hign-concerned Chemical | None |
| Power Supply | DRY BATTERY |
| Protection Level | IP67 |
| Fit Door Thickness | 35-55mm |
| Suitable Door Type | Steel Door,Wooden Door,Brass Door,Stainless Stell Door |
| Included Components | yes |
| Special Features | Builted-in Gateway,Support Gateway |
| Finish Type | Powder Coated |
| Doorknob Funcition | Biometric,Key & Keypad |
| Connectivity | WIFI |
| Ways To Unlock | APP,Mechanical Keys,Card,WIFI,Password,FINGERPRINT |
| Material | aluminium alloy |
| Handle Direction | Direction Reversible |
| Model Number | B05 |
| Origin | Mainland China |
| Smart home platform | other |
| Battery not included | 4pcs*1.5v AA battery |
| Support | USB Emergency Battery open the door,Phone NFC Function open the door |
